Stick Packing and Weighing Machine, SP-W12

Stick Packing and Weighing Machine, SP-W12
Request a Quote

Truking Feiyun manufactures stick pack machines to suit a variety of oral solution, mouthwash, and other pharmaceutical dosage of liquid and viscous products packed in stick sachets.

Request a Quote
Technical Specifications
Overall dimensions 2810mm(L)x1560mm(W)x1500mm(H)
Weight 1000kg
Basic parameters Load cell brand HBM
Weighing range 1g-300g
Scale value 0.002g
Accuracy ±0.01g
Max. packaging speed 60 cuts/min
Number of lanes 12 lanes
Lane pitch ≤50mm
Applicable pack size 10mm≤W≤25mm, 50mm≤L≤200mm, 5mm≤H≤20mm
Working temperature 0℃-40℃
Noise level ≤75db
Electric and air requirements Main power supply Three phase AC380V-50Hz-5-wire
Weighing power supply 220VAC±10%, single phase, 50/60㎐
Rated power 5kW
Compressed air consumption Quick change adapter: Ø12mm Air hose: 200L/min (0.6MPa-0.8MPa)
