Stick Packing and Arranging Machine, SP-S12 Series
This stick pack and arranging machines is suitable for packaging oral solution, mouthwash, and other pharmaceutical dosage of liquid and viscous products in stick sachets.
Technical Specifications
| Overall dimensions | 2900mm(L)×2450mm(W)×3320mm(H) |
| Weight | 3000kg |
| Applicable bag size | 50mm≤L≤200mm, W≤60mm |
| Max. packaging speed | 720 bags/min |
| Packed height | ≤90mm, 1-3layers |
| Discharging stations | 1-4 stations |
| Discharging size | Max. size: 220×200×90mm |
| Discharging height | 900±30mm |
| Partition | 200~400g/m2 cardboard |
| Noise level | ≤75db |
| Main power supply | Three phase AC380V-50Hz-5-wire |
| Rated power | 16kW |
| Compressed air consumption | Quick change adapter: Ø16mm Air hose: 500L/min (0.6MPa-0.8MPa) |
